PLC stamp micro 2 Evaluation board

Evaluation Board for HomePlug Green PHY® based Powerline Communication.

Evaluation Board for PLC Stamp micro

The kit is the ideal basis for evaluation and development of Homeplug Green PHY® based hardware and software. The hardware for this kit is built around the Qualcomm QCA7000 which is embedded on the included PLC Stamp micro. The Kit is useful for development of building automation components as well as electric vehicle charging electronics.

Features

PLC stamp micro 2 Evaluation board
Powerline Controller
Qualcomm QCA7000
Power Supply
5 V via USB
Connection to Mains
On PLC Stamp micro Evaluation Kit
Data Rate over Powerline
10 Mbit/s max.
Reach
300 m max.
Transformer
1:4:5 and 1:1:1 Winding Ratio
Order Number
I2PLCAMC-ISC-002-EVB
Unit Price
PLC stamp micro 2 Evaluation board
Powerline Controller
Qualcomm QCA7000
Power Supply
5 V via USB
Connection to Mains
On PLC Stamp micro Evaluation Kit
Data Rate over Powerline
10 Mbit/s max.
Reach
300 m max.
Transformer
1:4:5 and 1:1:1 Winding Ratio
Order Number
I2PLCAMC-ISC-002-EVB
Unit Price

Downloads
